Monday, 21. December 2015


FsAdvent: Automatic re-build and background tasks for suave.io websites

Filed under: Visual Studio,.NET,F#,FAKE - F# Make — Steffen Forkmann at 14:12 Uhr

[This post my second entry of the F# advent calendar 2015 series. You can also read the first post about “Using Async.Choice in Paket“]

Recently I was asked to help with a website that was based on suave.io. The task was to transform the existing F# script based suave.io website to something that can be run in the enterprise infrastructure and also performs some background tasks like creating Excel reports recurringly.

Suave as a (windows) service

A lot of the suave.io samples work with simple .fsx script files. This approach is indeed simple and allows fast prototyping with the use of the REPL. Even more complex websites like fssnip.net are using this approach with great success (code here). One of the benefits of script based suave solutions is that they are often equipped with a FAKE build script that rebuilds the website automatically if someone changes a file. One prominent example is FsReveal:

But sometimes you want to have a “real Visual Studio project” with debugging support and your enterprise might want to install your website as a Windows service. So the first step was to convert the F# script based approach into a project and adding TopShelf layer to make it runnable as Windows service. Thanks to a short blog post by Tomas Jansson this was super easy. It’s basically just installing TopShelf.FSharp via Paket and adding a single file with the config. Look into Tomas’s blog post to see the details.

After moving to the TopShelf model we still wanted to have automatic website rebuild whenever someone touched the source code. This little FAKE script makes this possible:

Running background jobs

The website already allowed to generate Excel reports by clicking somewhere in the UI. In addition to that we wanted to create the Excel reports recurringly in background jobs. Scott Hanselman has a blog post about “How to run Background Tasks in ASP.NET” and shows a couple of solutions that while optimized for ASP.NET would probably work with suave.io as well. But in this case we wanted to have something that syncronizes with the IO of the website so we decided to use F#’s MailboxProcessor feature a.k.a. “agents”. (As always: Scott Wlaschin has a nice introduction to agents.)

As a small intro into background jobs we start with F# counter agent sample by Tomas Petricek:

This little snippet shows an agent that calculates averages of the messages that it receives. Now let’s add a background job that recurringly sends messages to the counter agent:

In order to use this we need a bit of ugly infrastructure code that we will hide in a library:

So let’s try this out in the F# interactive:

Since this works as expected we can use it in our website:

Since all the user triggered reporting will also go through this taskAgent we ensure that IO is synchronized.

Sample project

In https://github.com/forki/backgroundjobs you can find a sample project which does exactly the two points from above.

As you can see the website performs background jobs and is rebuilding/restarting automatically when a source code file is saved.

Tags: , ,

Monday, 30. November 2015


F# advent calendar: Using Async.Choice in Paket

Filed under: Diverses,.NET,C#,F#,PLINQ — Steffen Forkmann at 0:50 Uhr

[This post is part of the F# advent calendar 2015 series.]

Prologue: What is Paket?

Paket is a dependency manager for .NET with support for NuGet packages and GitHub repositories. It enables precise and predictable control over what packages the projects within your application reference. If you want to learn how to use Paket then read the “Getting started” tutorial and take a look at the FAQs.

Paket file structure

Async computations in F#

Asynchronous Workflows are a very old F# feature (they already shipped in 2007) and they are used in many places in Paket. In this article I want to highlight one of the nice applications that F#’s async model allows you.

Many readers are probably familiar with C#’s async and await keywords (IIRC released with C# in 2012), but F#’s async feature works a little different. You can read more about some of “Asynchronous gotchas in C#” in Tomas Petricek’s excellent blog post. Most of these gotchas come from the fact that C# is starting all async tasks automatically while F# wraps the logic in data and allows you to run it explicitly. For a really good introduction to asynchronous programming with F# I can recommend Scott Wlaschin’s blog post.

The issue: retrieving version numbers from NuGet feeds

Paket’s package resolution algorithm (if you are interested in algorithms then read more) needs to know which versions are avalaible for a given package. Usually users specify more than one NuGet feed and different NuGet feeds support different protocols. The following code shows how older Paket versions retrieved all version numbers for a given package across all configured NuGet feeds:

As you can see getAllVersions tries 4 different NuGet protocols per source and returns the first result that is not None. Every getVersionsViaProtocol call performs async web request. In GetAllVersions we run this function for every NuGet source in parallel and combine the results. This code is very similar to the “async web downloader” sample in Scott Wlaschin’s async blog post and basically the “hello world” of asynchronous programming.

Code cleanup

The getAllVersions is deeply nested and it’s hard to understand what’s going on. With the help of List.tryPick we can rewrite the code as:

List.tryPick returns the first result that is not None. So instead of nesting multiple match and let! expressions we use a higher-order-function to encapsulate the same pattern.

Introducing Async.Choice

After using this code for a while in Paket we noticed that different NuGet server implementations each implement a different subset of the 4 protocols and differ very much in the response times. So there was no order of the protocols that would work good for all server implementations. But what if we could query all 4 protocols in parallel and just take the fastest response?

The change is relatively easy and we can rewrite the GetAllVersions as:Instead of running the web requests synchronously and in order we run the four web request per NuGet feed in parallel and take the first response that is not None.

Implementation of Async.Choice

Unfortunately Async.Choice is not part of the standard FSharp.Core library and it turns out it is not easy to implement. There are many different implementations floating around on the internet. The one we use in Paket is by Eirik Tsarpalis and taken from fssnip. One of the advantages of this version is that the automatic cancellation of tasks works nicely. Since we are running lots and lots of web requests in parallel and always take the first response we want to cancel all the other pending web requests. Otherwise we would basically DDOS the feeds with useless requests (and yes that happened to us ;-)). Since Async.Choice is very useful we sent a pull request to the Visual F# project and hope that one day it will be in the box.

Epilogue

Treating computations as data has even more advantages. The m-brace project created a new version of computation workflows called “cloud”:

cloud is a computation workflow builder and allows you to run your computations in the cloud. In contrast to async we don’t only control when something gets executed but also where. They even have a Cloud.Choice, which allows you to run tasks asynchronous in the cloud and take the first succeeding result.

Btw: async and cloud aren’t language keywords like C#’s async and await, but implemented as normal F# code in libraries. If you want to define your own computation expression builders, then the MSDN docs are a good starting point.

Tags: , , ,

Wednesday, 14. October 2015


Crazy stuff people do with FAKE and Paket – 1 of n

Filed under: Visual Studio,.NET,C#,F#,FAKE - F# Make — Steffen Forkmann at 11:33 Uhr

As many readers already know I’m maintaing the open source projects FAKE and Paket. These projects are used in many companies and open source projects to make continuous integration work on .NET and mono.

In this article series I want to highlight some of the more unsual use cases. Today I want to start and highlight the first 6 amazing projects.

FsReveal

FsReveal allows you to write beautiful slides in Markdown and brings C# and F# to the reveal.js web presentation framework.” [project site]

FsReveal uses Paket’s GitHub file dependencies feature to download reveal.js:

FsReveal GitHub references

It also uses a FAKE build script which converts Markdown files to html slides (via FSharp.Formatting) and runs these slides in a suave.io web server. FAKE’s file system watcher + suave’s socket implementation even allows you to edit your slides with automatic preview:

FSReveal

Stanford.NLP.NET

Stanford.NLP for .NET is a port of Stanford NLP distributions to .NET.

This project contains build scripts that recompile Stanford NLP .jar packages to .NET assemblies using IKVM.NET, tests that help to be sure that recompiled packages are workable and Stanford.NLP for .NET documentation site that hosts samples for all packages. All recompiled packages are available on NuGet.” [project site]

This project downloads .jar packages via Paket’s HTTP dependencies feature, recompiles everything to .NET via IKVM.NET in a FAKE build script and republishes it on NuGet. Automatic Java to .NET compilation – how cool is that?

Stanford NLP HTTP reference

Paket.VisualStudio

“Manage your Paket dependencies from Visual Studio!” [project site]

Paket.VisualStudio is a VisualStudio addin that you can download from Microsoft’s VisualStudio gallery. Unfortunately even in 2015 Microsoft doesn’t provide an API for automating the upload to its gallery. Therefore Paket.VisualStudio uses Paket’s NuGet dependencies feature to download canopy and Selenium:

Paket.VS

It then uses canopy + Selenium in a FAKE script to upload the addin via browser automation:

VS Gallery

Ionide-F#

“It’s part of Ionide plugin suite. F# IDE-like possibilities in Atom editor” [project site]

Ionide is an Atom plugin written in F#. It’s using Paket and FAKE to automate the build and release process.

First it uses FunScript to transpile F# to Javascript and then automates npm to resolve Javascript dependencies and apm to upload the plugin to the Atom gallery.

Akka.Net

Akka.NET is a community-driven port of the popular Java/Scala framework Akka to .NET.” [project site]

Akka.Net is a big (mainly C#) open source project that uses FAKE and Paket. One interesting observation is that it needs to create different xUnit addins and therefore uses Paket’s groups feature to maintain the xUnit versions.

Akka.Net

FSharp.Data

“The F# Data library implements everything you need to access data in your F# applications and scripts. It implements F# type providers for working with structured file formats (CSV, HTML, JSON and XML) and for accessing the WorldBank data. It also includes helpers for parsing CSV, HTML and JSON files and for sending HTTP requests.” [project site]

One of the many interesting things in FSharp.Data’s build is that it uses Paket to retrieve the FSharp.TypeProviders.StarterPack. These files need to be included in any F# type provider project and Paket allows you to manage this easily.

FSharp.Data

Tags: ,

Saturday, 5. July 2014


Microsoft, Open Source development and Codeplex

Filed under: Diverses,.NET,C#,F# — Steffen Forkmann at 12:37 Uhr

Recently Microsoft released all their major programming languages as open source and even started to accept pull requests. I didn’t think this would ever be possible at Microsoft, but they opened up and people like me started to contribute:

Personally I sent 29 (mostly small) pull requests to the Visual F# project. 5 pull requests already got accepted and 15 are still under evaluation.  In principle the development process seems to be working very well. Especially in the Visual F# project Don Syme and the Visual F# team are doing an excellent job to encourage the community. They are marking user voice issues as “approved in principle” and even provide detailed documents for implementation tasks (See CoreLibraryFunctions). This makes it very easy to get started and to hack a bit on the F# compiler. A big thanks to you guys.

A very important part of the open source is the review process. The F# community is awesome in this regards. On issues like a new “compareWith” function I got comments with remarks about coding style, test cases, documentation and lots of new ideas about possible performance improvements. It’s really exciting to be part of such an active and welcoming community. There is only one “but” and this “but” is the choice of the development platform. I really think CodePlex is hindering these projects to become even more successful. In this post I want to show some of my experiences with Codeplex. Remember I already sent 29 pull requests so I think it’s fair to say I tried!

Overall usability

The first impression on the Codeplex site is that every click feels so frustrating slow. Waiting 4s and more for a site to load doesn’t exactly feel like 2014.

If you want to comment on something then there is an “interesting” distinction between issues and pull requests. On issues you get a preview box and some buttons to make formatting easier, but you can’t edit your comments later:

Issue comment editor

On pull request you can edit your comments later but your don’t have the formatting buttons:

Pull request comment editor



E-Mail notifications

Like most online portals you can enable E-Mail notifications on Codeplex. Unfortunately it doesn’t really work. I tried to set all notification sliders I found to the max. and still don’t get notifcations if someone sends a new pull request to the Visual F# projects. Instead I’m getting annoying E-Mail notifications on my own activities:

E-Mail notifications on own comments



Things like this make you wonder if they actually dogfood their own stuff.

Code reviews on pull requests

As described above good code reviews are a very important part of any software development project, for open source programming language projects even more so. Unfortunately Codeplex has a really bad code review tool. I mean it is possible to comment on diffs:

Comments on diff

But if you update the pull request with a fix then the comment is displayed on the new fixed code and makes no sense any more:

Wrong code comments on diff

The whole code review is broken when you add commits to a pull request and it get’s even messier when you rebase your pull request on the current master. Rebasing pull requests is a very common operation in open source projects since it allows to move the merge effort from the project maintainer to the contributor. But unfortunately Codeplex gets confused by the rebase and now shows a wrong diff:

Wrong diff on rebased pull requests

A code platform shows a wrong diff – yep I couldn’t believe it myself so I tried again. #7040, #7045#7060, always the same.

Finding the needle in the hashstack

A couple of days ago I wanted to tweet a link to a cool performance trick and knew it was the last commit on a pull request. Now try to find the url:

Alphabetical order by hash

Yes that’s right – the commits are ordered in alphabetical order BY HASH or as I call it in “least useful order”.

Reporting Codeplex issues

Of course you may ask: “Steffen why didn’t you report these issues to the Codeplex team?” and that’s a valid question. Actually I went to codeplex.codeplex.com, which I believe is the home of the Codeplex project, and looked at their issue list. This is what I got:

Codeplex has quite some issues



Not a single issue on the first page is related to Codeplex and it seems they don’t even care to close this spam. So why should I care to log issues there?

What now?

It’s more than obvious – use the “move source code to github” strategy and people already created an issue on the TypeScript project. Unfortunately it got closed:

Business needs

After reading this I really doubt it was the decision of the teams to use Codeplex. Fortunately the ASP.NET team seems to be an exception to this. Somehow they managed to move to github.com/aspnet.

There are also other ways. Microsoft could really invest in Codeplex and make it a usable platform. But I don’t see this happing, because it will cost A LOT of money. Even if they would open source Codeplex I don’t see a community which is willing to improve this site.

So I appeal to the people in charge at Microsoft please answer the following questions:

  • What are the reasons for putting the Visual F# project on Codeplex, especially when the majority of the existing F# projects and community already operate on Github?
  • Do you think it’s more important to support Codeplex or to grow a community around the programming language projects?
  • If the F# community voted for the project to be moved, would you consider moving it?
  • If you insist on Codeplex how and when do you plan to fix these usability issues?

So please let your OSS teams and their community pick the open source platform they want!

Wednesday, 15. January 2014


FSharp.Configuration 0.1 released

Filed under: Informatik,C#,F# — Steffen Forkmann at 13:40 Uhr

As part of a longer process of making FSharpx better maintainable I created a new project called FSharp.Configuration. It contains type providers for the configuration of .NET projects:

Yaml type provider

Additonal information:

Please tell me what you think.

Tuesday, 14. January 2014


FSharpx.Collections 1.9 released

Filed under: .NET,Informatik,C#,F#,FAKE - F# Make — Steffen Forkmann at 11:29 Uhr

I’m happy to annouce the new release of the FSharpx.Collections package on nuget.

Most important changes:

Please tell me if it works for you.

Tuesday, 16. April 2013


Don’t be that guy!

Filed under: C# — Steffen Forkmann at 9:21 Uhr

I love to work on open source projects, but from time to time I have my doubts. My friend Daniel Nauck created a wonderful open source licensing project (see my blog post) and now we had to see this:


I am not a lawyer and rebranding a tool might be permitted by the MIT license, but seriously what are they thinking?

They even removed license information from the source files.

// The above copyright notice and this permission notice shall be
// included in all copies or substantial portions of the Software.

It’s really ironic to violate the license of a licensing tool, but please don’t be that guy!

Tags: ,

Wednesday, 6. March 2013


License all the things with Portable.Licensing 1.0

Filed under: C#,F# — Steffen Forkmann at 10:20 Uhr

"Portable.Licensing is a cross platform open source software licensing framework which allows you to implement licensing into your application or library.

It is targeting the Portable Class Library and thus runs on nearly every .NET/Mono profile including Silverlight, Windows Phone, Windows Store App, Xamarin.iOS, Xamarin.Android, Xamarin.Mac and XBox 360. Use it for your Desktop- (WinForms, WPF, etc.), Console-, Service-, Web- (ASP.NET, MVC, etc.), Mobile (Xamarin.iOS, Xamarin.Android) or even LightSwitch applications."

[Project site]

Yep, you read this correct. This project gives you a free licensing tool for all .NET/mono platforms including stuff like Android and iOS. It’s hosted on github and already on nuget and the Xamarin store, so it’s pretty easy to use – even from F#.

Create a license

There is a really good documentation on the github project page (and there is even a sample implementation for a License Manager app), but just to give you a small glimpse:

Make sure to keep the private key private and distribute the public key with your app.

Validate a license

So try it out and don’t forget to thank Daniel Nauck for this awesome new tool.

Tags: , , ,

Sunday, 27. January 2013


Released new AssemblyVersion tasks for FAKE

Filed under: C#,F#,FAKE - F# Make — Steffen Forkmann at 16:11 Uhr

Today I released two new AssemblyInfo tasks for FAKE and marked the old one as obsolete. One advantage of the new tasks is that they only generate the specified attributes and no more. There are already a lot of predefined attributes but it’s also possible to specify new ones. Here is a small example:

Tags: , ,

Friday, 18. January 2013


Release of the WMI type provider on nuget

Filed under: Visual Studio,F# — Steffen Forkmann at 15:57 Uhr

Today I’m happy to annouce that we have a new type provider in FSharpx. Yesterday I ported the WMI type provider from the F# sample pack and released it as a nuget package. This type provider allows to use Intellisense on data from the Windows Management Instrumentation (WMI).

Create a new F# project in Visual Studio 2012 and install the FSharpx.TypeProviders.Management package via nuget. The package manager references two libraries and you have to remove the reference to Samples.Management.TypeProvider.DesignTime manually. After you reference System.Management you can start to access WMI:

You can find a lot more samples in the F# Sample pack.

Tags: ,
